PRINTING METHOD | Direct Thermal | |
PRINTING SPEED | 80mm/sec | |
PRINT WIDTH | 203DPI | |
PRINT LENGTH | 8 Dots/mm, 0.125pitch | |
EFFECTIVE PRINTING WIDTH | 48mm, 384dots/line | |
PAPER | TYPE | Thermal paper/ Label |
WIDTH | 25.4mm ~ 58mm | |
THICKNESS | 0.06mm ~ 0.16mm | |
ROLL DIAMETER | Max. Ø 56.0mm | |
ROLL CORE INNER DIAMETER |
12.5mm ± 0.5mm | |
RELIABILITY | TPH LIFE | 50km |
PULSE ACTIVATION |
50,000,000pulse or more | |
FONTS and GRAPHICS |
STANDARD FONTS | Seven resident fonts 12-48 pt. |
OPTIONAL | International Character Sets | |
GRAPHICS, LINE AND BOX DRAWING |
PCX and Bitmap | |
BARCODE | EAN-8, EAN-13, Code 39, ITF, UPC-A, UPC-E, Codarbar, Code 93, Code 128, PDF 417(2D), QR Code(2D), Maxicode(2D) |
|
EMULATION | ESC/POS Command compatible | |
DRIVER | Window Printer Driver(7, XP, 2000, 2003, VISTA, 32 & 64bit), Windows (CE 4.2 & 5.0 / Mobile 5.0), Linux Printer Driver, Symbian, Blackberry, Android(2.1~) |
|
SENSOR | Paper end /Black mark / Cover open sensors | |
INTERFACE | STANDARD | Serial(RS-232C), USB |
OPTION | Bluetooth class 2, Wi-Fi(802.11b/g) | |
BATTERY | External Charger(Output 8.4VDC/0.8A) | |
DIMENSION | WxDxH(mm) | 104 x154 x 74 |
W"xD"xH"(inch) | 4.0 x 6.0 x 2.9 | |
WEIGHT | 490g(With Battery) | |
TEMPERATURE | OPERATION | -10 ~ 50°C |
STORAGE | -20 ~ 60°C | |
HUMIDITY | OPERATION | 35 ~ 95% |
STORAGE | 10 ~ 95% |
