- Flexible Licensing Solution: Allows current scanning needs to be met while protecting the option to upgrade scanning capabilities in the future by simply purchasing a license for the appropriate feature
- Intelligent Multi-Interface Design: Supports all popular interfaces in one device, replacing the time consuming process of scanning programming bar codes with automatic interface detection
- TotalFreedom 2.0: Second-generation plug-in development platform enables the loading and linking of multiple applications directly onto the scanner, eliminating the need for host system modifications while offering expanded decoding and data formatting functionality
- Mobile Phone Reading: Easily scans bar codes directly from mobile device or computer screens, almost as if they were printed on paper
- High Visibility LED Aimer: Laser-free aiming provides an accurate scan indication, creating a customerfriendly operating environment while removing the risk of eye injury
- Remote MasterMind™ Ready: Reduces total cost of ownership by providing a turnkey remote device management solution that easily manages and tracks usage of installed devices
Specification
| Mechanical |
|
| Dimensions |
(LxWxH) 74 mm x 50 mm x 26 mm (2.9˝ x 1.9˝ x 1.0˝)
|
| Weight |
75g (2.7 oz) |
| Termination |
15-POS D-Sub connector |
| Electrical |
|
| Input Voltage |
5 VDC ± 0.25 V |
| Operating Power |
2.3 W (450 mA @ 5 V) |
| Standby Power |
0.45 W (90 mA @ 5 V) |
| Host System Interfaces |
USB, RS232, and Keyboard Wedge |
| Electrical |
|
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| Storage Temperature |
-20°C to 70°C (-4°F to 158°F) |
| Humidity |
5% to 95% relative humidity, non-condensing |
| Drop Designed to withstand |
1.5 m (5´) drops |
| Environmental Sealing |
IP53 |
| Light Levels |
0 to 100,000 lux (9,290 foot-candles) |
| Scan Performance |
|
| Scan Pattern Area |
Image (838 x 640 pixel array) |
| Motion Tolerance |
>270 cm/s (106 in/s) at focal point |
| Scan Angle |
Horizontal: 42.4°, Vertical: 33° |
| Focal Point |
127mm (5˝) |
| Print Contrast |
20% minimum reflectance difference
|
| Pitch, Skew |
±45°, ±65° |
| Decode Capability |
Reads standard 1D, PDF, 2D, Postal and OCR symbologies.
*Note: Decode capabilities dependent on kit configuration |
| Warranty |
2 year factory warranty |
